DONANIM ÖZELLİKLERİ
Arabirim3× 10/100Mbps LAN Ports
1× 10/100Mbps LAN/WAN Port
1× Nano SIM Card Slot
2× External SMA-F Antenna InterfaceButonWPS/Wi-Fi Button，Reset ButtonHarici Güç Kaynağı12V/1ABoyutlar ( W X D X H )6.85 × 4.9 × 1.32 in (174 × 124.5 × 33.5 mm)Anten2× Detachable External 4G LTE AntennasYAZILIM ÖZELLİKLERİ
Quality of ServicePrioritizes network traffic by device or applicationÇalışma Modları3G/4G Router, Wireless RouterWAN TürüDynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access)YönetimAccess Control, Local Management, Remote Management
reboot scheduleDHCPServer, Client, DHCP Client List, Address ReservationPort YönlendirmeVirtual Server, Port Triggering, UPnP, DMZDinamik DNSDynDns, NO-IPVPNPPTP VPN, OpenVPNErişim KontrolüParental Control, Local Management ControlFirewall GüvenliğiDoS, SPI Firewall, IP Address Filter/Domain Filter,
IP and MAC Address BindingProtokollerSupports IPv4 and IPv6Misafir Ağ2.4GHz guest network x 1, 5GHz guest network x 1KABLOSUZ ÖZELLİKLERİ
Kablosuz StandartlarIEEE 802.11a/n/ac 5 GHz, IEEE 802.11b/g/n 2.4 GHzFrekans2.4 GHz and 5 GHzBağlantı Hızı300Mbps at 2.4GHz, 867Mbps at 5GHzAlıcı Hassasiyeti5 GHz:
11a 54M: -77 dBm
11ac VHT20 MCS0: -95.5 dBm 11ac VHT20 MCS8: -73 dBm
11ac VHT40 MCS0: -93 dBm 11ac VHT20 MCS9: -68 dBm
11ac VHT80 MCS0: -90 dBm 11ac VHT20 MCS9: -65 dBm
2.4 GHz:
11g 54M: -74.5 dBm
11n HT20 MCS0: -92 dBm 11n HT20 MCS7: -73 dBm
11n HT40 MCS0: -89 dBm 11n HT40 MCS7: -70 dBmKablosuz FonksiyonlarEnable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless
StatisticsWAN FailoverYesKablosuz Güvenlik64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptionsİletim Gücü< 20 dBm (2.4 GHz), < 23 dBm (5 GHz)Ağ Türü4G: FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz)
TDD-LTE: B38/B40/B41 (2600/2300/2500 MHz)
3G: HSPA/UMTS: B1/B5/B8 (2100/850/900 MHz)OTHER
Network Services Enabled by DefaultWeb Server
Manage and configure device through web (HTTP/HTTPS)
• Port: 80/443 Protocol: TCP
DHCP Server
IP address assignment (DHCP)
• Port: 67 Protocol: UDP
DNS
• Port: 53 Protocol: TCP
App management
Manage and configure device through app
• Port: 22 Protocol: TCP
• Port: 20002 Protocol: TCP
CWMP
CPE WAN Management Protocol
• Port: 7547 Protocol: TCPDİĞERLERİ
SertifikaCEPaket İçeriğiAC1200 Wireless Dual Band 4G LTE Router, Archer MR402
RJ45 Ethernet Cable
1.5m Power Adapter
Quick Installation GuideSistem GereksinimleriMicrosoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10
MAC OS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0,
Safari 4.0 browsers or higher, or other Java-enabled browsers
Nano SIM Card
OrtamOperating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
